This 4-gang standard-size wall plate is constructed from durable painted metal cold-rolled steel and features a Red Semi-Gloss finish for a clean, durable appearance. Measuring 4.5 in. high x 8.187 in. wide, the 0.030-inch-thick plate provides four blank openings for installations requiring a continuous blank cover. The box mounting configuration features mounting holes spaced 3.281 inches apart for secure installation. Its durable powder coat finish helps inhibit oxidation and provides resistance to chipping and scratching, making it suitable for a variety of electrical installations. Applications include residential, commercial, industrial, and institutional settings, when applicable. The wall plate is UL Listed and meets UL 514D requirements. It includes 1/2-inch standard slotted 6-32 oval-head screws in a matching finish for installation. Made in USA for dependable wall plate applications.

Product Specifications

• Gang: 4-Gang
• Size: Standard (4.5 in. high x 8.187 in. wide)
• Opening: (4) Blank
• Material: Painted Metal - Cold-Rolled Steel
• Finish: Red Semi-Gloss
• Mounting: Box, 3.281 in. between mounting holes
• Thickness: 0.030 inches
• UL Listed: Yes
• Standard: UL 514D
• Made in USA: Yes
• Applications: Residential, Commercial, Industrial, Institutional
• Screws: 1/2-inch standard slotted 6-32 oval-head screws in matching finish

Product Features

• Durable cold-rolled steel construction
• Red Semi-Gloss powder coat finish
• 0.030-inch steel thickness
• Standard-size 4-gang design
• Four blank openings
• Finish helps inhibit oxidation and resist chipping and scratching
• Box mounting configuration
• Includes matching screws
• UL Listed
• Suitable for residential and commercial applications
